Full-automatic Oyster Sauce filling machine

FOB Reference Price:Get Latest Price
1 Set/Sets (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Type:
Filling Machine
Condition:
New
Application:
Food, Beverage, Medical, Chemical
Packaging Type:
Bottles
Packaging Material:
Plastic, Glass
Automatic Grade:
Automatic
Driven Type:
electric & pneumatic
Voltage:
220V/50HZ
Power:
250W
Place of Origin:
Guangdong, China (Mainland)
Brand Name:
HC-pack
Model Number:
HCHS-8600B
Dimension(L*W*H):
about 2200*1150*1800mm
Weight:
about 380kg
After-sales Service Provided:
Engineers available to service machinery overseas
Filling range:
20-100ml;50-200ml;100-500ml;300-1000m;500-2000ml
Filling speed:
30-80 bots/min(100-500ml)
Filling precision:
Above (within)±1.5%
SupplyAbility
SupplyAbility:
10 Set/Sets per Month
Packaging & Delivery
Packaging Details
packaging size: about 2300*1200*1900mm
package: packed in wooden case with well-supported materials wrapped
Lead Time :
within 25 working days

Specifications

Oyster Sauce filling machine
1.hot sauce filling machine
2.PLC and touch screen control
3.leakage-proof device
4.automatic c

Full-automatic Oyster Sauce filling machine

Main use:



     The machine is widely used for full-automatic filling semi-liquid, ointment, paste, dense catsup and all kinds of materials with granule in it such as fruit drinks, honey, syrup, jam, peanut butter, sesame paste, tomato sauce, chili sauce, etc.



Main features and performance:

  1.   The filling machine employs plunger type to measure the filling quantity and linear type to feed bottles, integrated with the electric and pneumatic components which are world- renowned brands of low failure rate, stable performance and long service life;
  2.   The filling machine is controlled by PLC along with touch screen with high precision, tight structure and excellent appearance;
  3.   The frame and body of machine are made of high-quality 304 stainless steel and food grade plastics with good appearance, easy cleanliness and corrosion resisting, in conformity with GMP standards;
  4.   Photosensor, approximate switch and other elements are products of international famous brand which can make sure no filling when no bottle and automatically control the filling level;
  5.   Due to its strong adaptability and convenient adjustment, this machine can fill different types of bottles without changing any components;
  6.   The charging basket shares the functions of automatic control of feeding material and stirring; the filling head is equipped with a leakage-proof device to make sure no drip when filling;
  7.   The plunger and sealing element are made from PTEF which is corrosion-resistant, damage-resistant and high temperature resistant. It can be used for filling materials under 95 degrees.



Main technical parameters:



Model

HCHS-8600B

Filling heads

Eight

Filling range

20-100ml;50-200ml;100-500ml;300-1000m;500-2000ml

Filling speed

30-80 bots/min(100-500ml)

Power

Pressure :220V/50HZ   Power:250W

Filling precision

Above (within)±1.5%

Air source

0.4-0.6Mpa
