Semi automatic wine BIB filling machine

FOB Reference Price:Get Latest Price
1 Set/Sets (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Type:
Filling Machine
Condition:
New
Application:
Beverage, Chemical, Food, Medical
Packaging Type:
Bags
Packaging Material:
Plastic, aluminium foil bag
Automatic Grade:
Semi-Automatic
Driven Type:
electric & pneumatic
Voltage:
220V/50HZ
Power:
380W
Place of Origin:
Guangdong, China (Mainland)
Brand Name:
HC-pack
Model Number:
HCBIB-130SA/B
Dimension(L*W*H):
about 600*800*1200mm
Weight:
about 200kg
After-sales Service Provided:
Engineers available to service machinery overseas
Filling range:
2-10L; 10L-30L
Filling speed:
220-240 bags/h
Filling precision:
Above (within)±0.2%
SupplyAbility
SupplyAbility:
10 Set/Sets per Month
Packaging & Delivery
Packaging Details
packaging size: about 600*800*1200mm
package: packed in wooden case with well supported materials wrapped
Lead Time :
within 25 working days

Semi automatic wine BIB filling machine

Main use:



     The machine is widely used for bag-in-box filling and capping such liquid materials as grape wine, edible oil, fruit juice, additives, milk, syrup, alcoholic beverages, concentrated seasonings and etc.



Main features and performance:

  1. This filling machine employs a flow meter to measure the filling quantity which shares a perfect filling precision;
  2. It is controlled by PLC with accurate precision, advanced structure and stable performance;
  3. The parts contacting with the materials are made of high-quality stainless steel which makes the filling machine enjoys a beautiful appearance, environmental friendliness and easy to dismantle, as well as in conformity with GMP standards;
  4. The working process of this filling machine: manually putting the bag in place—manually controlling the manipulator—automatic pulling out the cap—filling—automatic pressing the tap;
  5. A nitrogen system can be added according to the client’s requirement;
  6. The electric and pneumatic components are products of world-renowned brands with low failure rate, reliable performance and long service life.

Main technical parameters:



Model

HCBIB-130SA/B

Filling head

One

Filling range

2-10L; 10L-30L

Filling speed

220-240 bags/h

Power

Pressure :220V/50HZ     Power:380W

Filling precision

Above (within)±0.2%

Air pressure

0.4-0.6Mpa
