Full-automatic Negative Pressure tea drank filler

FOB Reference Price:Get Latest Price
US $19,050-19,500 / Sets | 1 Set/Sets (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Type:
Filling Machine
Condition:
New
Application:
Beverage, Chemical, Food, Medical
Packaging Type:
Bottles
Packaging Material:
Glass, Plastic
Automatic Grade:
Automatic
Driven Type:
electric & pneumatic
Voltage:
220V/50HZ
Power:
1800W
Place of Origin:
Guangdong, China (Mainland)
Brand Name:
HC-pack
Model Number:
HCF-10
Dimension(L*W*H):
about 4800*1200*1800mm
Weight:
about 600kg
After-sales Service Provided:
Engineers available to service machinery overseas
Filling range:
80-500ml; 500-2000ml
Filling speed:
40-60 bots/min
Filling precision:
Above (within)±3mm
Supply Ability
Supply Ability:
10 Set/Sets per Month
Packaging & Delivery
Packaging Details
packaging size: about 4800*100*1800mm
package: packed in wooden case with well-supported materials wrapped
Lead Time :
within 25 working days

Main use:



     The machine is widely used for full-automatic filling various kinds of easy-flowing and easy-blistering liquid in food & beverage, medicine, chemicals, pesticide industries, such as tea drinks, soy, wine, vinegar, and liquids with acid, alkali, organic solvents, or xylene.



Main features and performance:



  1. Negative pressure filling can make the liquid level of each container stay at the same height and can effectively eliminate the foam during the filling period;
  2. This liquid filler is controlled by PLC and touch screen with accurate precision, advanced structure and stable running;
  3. The parts contacting with materials are made of high-quality stainless steel which shares an excellent appearance, environmental friendliness, easy dismantle and cleanliness, as well as in conformity with GMP standards;
  4. Photosensor, approximate switch and other elements are products of international famous brand which can make sure no filling when no bottle and automatically control the filling level;
  5. Due to its strong adaptability and convenient adjustment, this machine can fill different types of bottles without changing any components;
  6. The electric and pneumatic components are products of world- renowned brands of low failure rate, stable performance and long service life;
  7. It is simple to adjust both the filling quantity and filling speed; the filling head is equipped with a leakage-proof device to make sure no drip when filling.



Main technical parameters:



Model

HCF-10

Filling heads

Ten

Filling range

80-500ml; 500-2000ml

Filling speed

40-60 bots/min

Power

Pressure :220V/50HZ   Power:1800W

Filling precision

Above (within)±3mm

Weight

About 600kg



HCF-10
