HCXG-150B Full-automatic Glass Bottle Capping Machine

FOB Reference Price:Get Latest Price
1 Set/Sets (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Type:
Capping Machine
Condition:
New
Application:
Food, Beverage, Medical, Chemical, sauce
Driven Type:
Electric
Automatic Grade:
Automatic
Voltage:
220V/50HZ
Power:
2800W
Packaging Type:
Bottles
Packaging Material:
Glass
Place of Origin:
Guangdong, China (Mainland)
Brand Name:
HC-pack
Model Number:
HCXG-150B
Dimension(L*W*H):
2600*1100*1950mm
Weight:
About 600kg
After-sales Service Provided:
Engineers available to service machinery overseas
SupplyAbility
SupplyAbility:
10 Set/Sets per Month
Packaging & Delivery
Packaging Details
packaging size:1500(L)*1100(W)*1850(H)mm
package: packed in wooden case wrapped by well-support materials
Lead Time :
about 25 working days

Specifications

1.screwing glass bottle cap
2.using rub typet to screw cap
3.cap conveying structure is equipped with a photoelectric sensor

Main use:

    The machine is widely used for full-automatic screwing glass bottle cap in foods & beverage, sauce, medicine, chemicals industries and so on.



Main features and performance:

  1. The machine consists of bottle conveying structure, cap arranging structure, bottle nipping structure, cap screwing structure and electric control system. It features high automation, reasonable design, tight structure and convenient operation;
  2. The frame and body of machine are made of high-quality 304 stainless steel with good appearance and easy cleanliness, in conformity with food hygiene standards;
  3. Using rub type screw cap makes it own a reasonable structure, stable and reliable performance, high working efficiency and helps solve some disadvantages such as skidding and attrition of caps;
  4. The interval and height of the screwing structure can be adjusted quickly to adapt different types of bottles and caps;
  5. The cap conveying structure is equipped with a photoelectric sensing device to make sure its safety of” starting when no cap; shutting up when full of caps.’ In this way, the machine can run more stable and reliable.



Main technical parameters:



Model

HCXG-150B

Cap Diameter

φ28-φ50mm   φ50-φ8mm

Bottle Diameter

φ28-11mm



Bottle Height

60-280mm

Capping Speed

50-90bots/min

Power

Pressure :220V/50HZ     Power   :2800W

Air pressure

0.6-0.8Mpa

Dimension

2600*1100*1950mm

Weight

About 600kg





Machine Packing:









































































































































































































































Our Factory Photo:
