Ten-heads Full-automatic Negative Pressure Liquid Filler

FOB Reference Price:Get Latest Price
1 Set/Sets (Min. Order)
Report Suspicious Activity
Supply Ability
Supply Ability:
10 Set/Sets per Month
Packaging & Delivery
Packaging Details
packaging size: about 4800*100*1800mm
package: packed in wooden case with well-supported materials wrapped
Lead Time :
within 25 working days


1.Negative pressure filling
2.PLC and touch screen control
3.automatically control the filling level
4.a leakage-proof device

Main use:


     The machine is widely used for full-automatic filling various kinds of easy-flowing and easy-blistering liquid in food & beverage, medicine, chemicals, pesticide industries, such as tea drinks, soy, wine, vinegar, and liquids with acid, alkali, organic solvents, or xylene.


Main features and performance:


  1. Negative pressure filling can make the liquid level of each container stay at the same height and can effectively eliminate the foam during the filling period;
  2. This liquid filler is controlled by PLC and touch screen with accurate precision, advanced structure and stable running;
  3. The parts contacting with materials are made of high-quality stainless steel which shares an excellent appearance, environmental friendliness, easy dismantle and cleanliness, as well as in conformity with GMP standards;
  4. Photosensor, approximate switch and other elements are products of international famous brand which can make sure no filling when no bottle and automatically control the filling level;
  5. Due to its strong adaptability and convenient adjustment, this machine can fill different types of bottles without changing any components;
  6. The electric and pneumatic components are products of world- renowned brands of low failure rate, stable performance and long service life;
  7. It is simple to adjust both the filling quantity and filling speed; the filling head is equipped with a leakage-proof device to make sure no drip when filling.


Main technical parameters:




Filling heads


Filling range

80-500ml; 500-2000ml

Filling speed

40-60 bots/min


Pressure :220V/50HZ   Power:1800W

Filling precision

Above (within)±3mm


About 600kg
