Full-automatic bottle filling machine

FOB Reference Price:Get Latest Price
US $14,000-18,000 / Sets | 1 Set/Sets (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Type:
Filling Machine
Condition:
New
Application:
Food, Beverage, Medical, Chemical
Packaging Type:
Bottles
Packaging Material:
Plastic, Glass
Automatic Grade:
Automatic
Driven Type:
electric & pneumatic
Voltage:
220V/50HZ
Power:
500W
Place of Origin:
Guangdong, China (Mainland)
Brand Name:
HC-pack
Model Number:
HCHS-6600
Dimension(L*W*H):
about 1800*1150*1800mm
Weight:
about 350kg
After-sales Service Provided:
Engineers available to service machinery overseas
Filling range:
100-500ml;300-1000m;500-2000ml
Filling speed:
20-70 bots/min (filling 100-500ml )
Filling precision:
Above (within)±1.5%
SupplyAbility
SupplyAbility:
10 Set/Sets per Month
Packaging & Delivery
Packaging Details
packaging size: about 1800*1150*1800mm
package: packed in wooden case with well-supported materials wrapped
Lead Time :
within 30 working days

Specifications

1.full-automatic filling paste
2.piston type, six-heads
3. PLC control
4.with a leakage-proof devic

 Full-automatic bottle filling machine

 Main use:



     The machine is widely used for automatic filling semi-liquid, ointment, paste, dense catsup and all kinds of materials with granule in it, such as fruit flesh juice, honey, syrup, jam, peanut butter, sesame paste, tomato sauce, chilli sauce, etc.





Main features and performance:



  1. The filling machine employs plunger type to measure the filling quantity and linear type to feed bottles, integrated with the electric and pneumatic components which are world- renowned brands of low failure rate, stable performance and long service life;
  2. The filling machine is controlled by PLC along with touch screen with high precision, tight structure and excellent appearance;
  3. Photosensor, approximate switch and other elements are products of international famous brand which can make sure no filling when no bottle and automatically control the filling level;
  4. The charging basket shares the functions of automatic control of feeding material and stirring; the filling head is equipped with a leakage-proof device to make sure no drip when filling;
  5. The plunger and sealing element are made from PTEF which is corrosion-resistant, damage-resistant and high temperature resistant. It can be used for filling materials under 95 degrees;
  6. Due to its strong adaptability and convenient adjustment, this machine can fill different types of bottles without changing any components;
  7. The frame and body of machine are made of high-quality  stainless steel and food grade plastics with good appearance, easy cleanliness and corrosion resisting, in conformity with GMP standards.



Main technical parameters:





Model

HCHS-6600

Filling heads

Six

Filling range

20-100ml,50-200ml, 100-500ml, 300-1000m, 500-2000ml

Filling speed

20-70 bots/min (100-500ml )

Power

Pressure :220V/50HZ     Power   :250W

Filling precision

Above (within)±1.5%

Air source

0.4-0.6Mpa
